ENERGY EFFICIENT CAST RESIN DRY TYPE TRANSFORMERS


../assets/img/products/Yuksek-Verimli-Dokme-Recineli-Kuru-Tip-Transformatorler.jpg

ELKİMA Trafo values environment, nature and atmosphere. Therefore we always strive towards innovation which may positively affect nature.

ELKİMA Trafo produces EcoFriendly wound core transformers beyond the latest efficiency standards such as European Directive 2009/125/EC and MEPS.

  • Less Carbon footprint
  • More than 20% Lower Losses
  • Higher efficiency
  • Compact design
  • Very Low Noise level
  • Fully Complies with European Directive 2009/125/EC

APPLICATION

  • Hospitals
  • Airports
  • Residences
  • Schools
  • Offfshore – Oil Industry Applications
  • Military Bases
  • All Crowded Places

DESIGN

  • Up to 36kV and 5MVA
  • 50-60Hz.
  • 3 Phase
  • E2/C2/F1
  • F/H Insulation – Thermal Class
  • Indoor - Outdoor applications
  • IP00-IP21-IP23-IP31-IP44

FEATURES

  • Safely (self extinguishing, fire safe)
  • Maintenance Free
  • Environmental Friendly (No Oil Leakage Risk)
  • High hotspot Temperature (F-155’C, H-180’C)
